Operating regulations of portable rebar bender

1. Check whether the mechanical properties are good and the tables and curved countertops are kept horizontally; and various core axis tool gear is prepared.

2. Install the core shaft according to the diameter of the processing steel bars and the requirements of the bending machine, forming a shaft, an iron shaft or a variable gear, and the diameter of the core shaft should be 2.5 times the diameter of the reinforcement.

3.check the core shaft, the block and the turntable should not be damaged and cracking, the protective cover is tight and reliable, and the operation is confirmed to work normally by the aircraft.

4.during the operation, insert one end of the reinforcement to bend in the gap fixed in the turntable, and the other end is fixed with the fuselage and tightened with the hand. Checking the fixed body fixing.

5. In the operation, it is strictly forbidden to replace the core shaft and change angle and speed adjustment.

6. When curved steel bars, it is strictly forbidden to process the diameter, roots and mechanical speed of the steel bars stipulated in the mechanical regulations.

7. When the curved high hardness or low alloy steel bar, the maximum diameter of the standard is replaced in accordance with the regulations of the mechanical nameplate, and the corresponding core shaft should be replaced.

8. It is strictly forbidden to stand in the operating radius of the curved reinforced bars and the side of the body with no fixed side. The bending semi -finished products should be stacked neatly, and the hooks must not be facing up.

9. when the turntable is changed, it must be carried out after stopping.

10. After the operation, cleaning the scene, maintenance machinery, power -off lock box.
