Electro hydraulic punching tool description: Suitable for iron, copper, aluminum, forming steel, channel steel, I-beam drilling operations, small size, light weight, easy to operate, labor-saving and rapid punching other advantages. This model is electro-hydraulic punching tool; Suitable for punching iron, copper, aluminum and other metal materials; Punching speed, positioning accuracy is not offset; Can make punching die of various shapes; Hydraulic punching can exempted chips produced during drilling are safer and cleaner during operation. They can be carried to the site or fixed in the factory for large-volume punching operations.
Model | JP20-100 Electric channel steel punching machine (long style) |
Motor power | 1200W |
Punching die | Round die |
Max. piercing dia. | 20.5mm |
Min. piercing dia. | 6.5mm |
Max. sheet thickness | 6mm |
Voltage | 110V/220V/230V |
Punching capacity | It is prohibited to punch the maximum aperture and thickness shown in the table above (can punch angle iron, 6mm iron plate and #10 channel steel) |
Punching speed | 2-3S |
Net weight | 15KG |
Gross weight | 20KG |
Height | 50cm |
